24 volt Dimmable power supply
Part number LP-30-24PT
Constant Voltage Design
Works with leading and trailing edge TRIAC dimmers
PWM Output
Protections: Short circuit/ Over Loading/ Over Current/ Over Temperature
Other features:
- AC input 200-240VAC
- Cooling by free air convection
- 85% efficiency
- 3 years warranty
- IP20 non waterproof
| Wattage | 30 | |
| Input Voltage | 180-240VAC | |
| Output Current | 1.25A | |
| Output Voltage | 24 | |
| Output Voltage Options | Single | |
| DC output adjustment | N/A | |
| Dimensions | 155x 54x 20 | |
| Working Temperature | -40~+70°C | |
| Safety Standards | EN61347-1, EN61347-2-13 | |
| EMC Standards | Compliance to EN55015, EN61000-3-2,3 (>60% load) | |
The 24 volt Dimmable power supply | LP-30-24PT | LED driver for LED strip is evocative, to say the least, but that's why you're drawn to it in the first place.
