24 volt Dimmable power supply
Part number LP-100-24PT
Constant Voltage Design
Works with leading and trailing edge TRIAC dimmers
PWM Output
Protections: Short circuit/ Over Loading/ Over Temperature
Other features:
- AC input 200-240VAC
- IP66 Design for outdoor installation
- Cooling by free air convection
- 84% efficiency
- 3 years warranty
| Wattage | 100 | |
| Input Voltage | 200-240VAC | |
| Output Current | 4.16A | |
| Output Voltage | 24 | |
| Output Voltage Options | Single | |
| DC output adjustment | N/A | |
| Dimensions | 230x 70x 46 | |
| Working Temperature | -40~+60°C | |
| Safety Standards | EN61347-1, EN61347-2-13 | |
| EMC Standards | Compliance to EN55015, EN61000-3-2 (>60% load) Compliance to EN61000-4-2,3,4,5,6,11 EN61547 | |
The 24 volt Dimmable power supply | LP-100 -24PT | LED driver for LED strip is a sensational customer favorite, and we hope you like it just as much.
