Pixel chasing LED strip warm | Leading24-PIX24 | 10.4 w/m- 120 LEDS/m

Pixel Chasing LED Strip warm white - Leading24-PIX24 (24V, Cut-to-Length, High CRI, 5-Year Warranty)

Bring warmth and atmosphere into your space with the Leading24-PIX24 Warm White Pixel Chasing LED Strip, the ultimate choice for dynamic, customisable LED lighting. Designed with 120 LEDs per metre and advanced pixel-chasing control, this professional-grade 24V LED strip allows each segment to be controlled independently. Create stunning running effects, fades, and animations that enhance restaurants, cinemas, gaming setups, gyms, shopping centres, retail displays, and modern home interiors. To work with Pixel controller offering 28 built-in modes, brightness adjustment, and smooth speed control, this product delivers both functionality and premium design.

Built for performance, the Leading24-PIX24 Pixel Chasing LED Strip supports long continuous runs of up to 24 metres - available in warm white 3000K for cosy ambience, as well as natural and cool white options for versatile applications. Using A-PIX amplifier, multiple strips can be powered together without signal loss, making it perfect for larger commercial lighting projects. For bespoke installations, our team can supply custom lengths with soldered cable tails to save time on-site.

Key Features:

• Control each LED segment independently - creating dynamic chasing patterns and animations.

• Dimmable: - Choose brightness to suit any setting.

• Easy Installation: Comes with heavy-duty 3M backing tape for secure and clean installation on walls, ceilings and other flat surfaces.

• Customisable Lengths: Cut the strip every 125mm to suit your specific requirements.

Available in Multiple Colours

Choose from a variety of colour temperatures:

• Warm White (3000K)

• Natural White (4000K)

• Cool White (6000K)

• RGB Digital -Colour Changing

❓ Frequently Asked Questions (FAQ)

🔹 Is Warm White Pixel Chasing LED Strip priced per metre?
Yes, 24V pixel chasing LED strip is priced per metre. Simply add the length(s) you need to your basket.

🔹 If I order 18 metres, will I receive one piece or 18 x 1m sections?
You will receive one continuous 18-metre LED strip unless you request otherwise.

🔹 Does it come with soldered cable tails?
Yes, orders of 20 metres in one run include 2m soldered cable tails free of charge. For shorter lengths, add cable tails during checkout or request longer tails if needed.

🔹 Can the strip be cut to size?
Yes, the strip can be cut every 125mm along the marked points for easy installation.

🛠️ Installation & Control Components:

Single Length Setup Add on:

 Soldered 2-core cable tail – supplied pre-fitted for quick and reliable connection.

 Plug-and-play soldered lead with pixel controller – enables instant setup with built-in pixel chasing control functions.

 Wireless wall controller with pixel control unit – provides seamless remote control of lighting effects, brightness, and speed.

Multiple Length Setup Add on:

 Soldered 3-core cable tails – designed for secure and reliable connections when powering multiple LED strip runs.

 Amplifier for Pixel Chasing LED strip – extends signal and power for long runs or multiple connected strips.

 Wireless wall controller & pixel controller unit (wired into amplifier)  - allows full remote control of effects, brightness, and speed across extended installations.

🔹  Correct size 24V power supply (per chart below)

 Optional aluminium profile – available for light diffusion, heat dissipation and a professional finish.

Power Supply Recommendations

Select the correct 24V power supply based on your strip length (max continuous run: 24 metres). Do not exceed power supply load or Pixel chasing max linear run length.

📋 Technical Specification

• Colour temperature: Warm White 3000K

• Part number: LS24PIX-120-WW20 (Leading24-PIX24)

• Brightness: Smooth pixel chasing warm glow

• Voltage: 24V constant

• Power consumption: 10.5W per metre

• LED density: 120 LEDs/m (8 pixels per metre)

• Lumen output: 1029 Lumens /m.

• Strip width: 10mm

• Cut points: Every 125mm

• Max continuous run: 24 metres

• Backing: Industrial-strength 3M adhesive

• IP rating: IP20 (indoor use)

• Dimmable: Yes

• CRI: High (accurate colour rendering)

• Lifespan: Up to 50,000 hours

• Warranty: 5 years

• Certifications: UL, TUV, CE, CB, ROHS

🛒 Ordering & Customisation

🔹 Priced per metre, dispatched as one continuous strip unless otherwise requested.
🔹 Cut-to-measure options with soldered cable tails available to purchase.
🔹 Specify lengths and soldering needs in the special instructions box at checkout.

🔹20 Metre Kit available to purchase.

📞 Support & Contact

Questions or advice? Contact our UK-based LED experts:

Phone: 02476 262328
Email: sales@leadingled.co.uk
Live Chat: Available on our website
WhatsApp: Scan our QR code

Bespoke, cut to measure project. Pixel chasing (Leading24-PIX) housed in surface profile part number: SP-001. Colour temperature: warm white (3000k) Pixel controller part number CW-PIX.  Complete with soldered cable tails, ready for installation on site.  Venue: Student accommodation games room.
