24v Dotless COB strip cool free cutting | Leading24-COB-FC | 10w/m | 528 LEDS/m - Dotless

Excluding VAT
  • Sale
  • Regular price £8.95
Shipping calculated at checkout.


24v Dotless COB strip cool free cutting - CUT & SOLDER ANYWHERE ALONG THE STRIP!

Leading24-COB-FC - An expertly designed lighting solution. With a density of 528 LEDs/m, this range provides full, uniform illumination.

The unique free cutting feature allows for easy, accurate customisation, matching your exact measurements - the ideal choice of strip for intricate, cut-to-measure projects.

High-end, world-class lighting - Ideal for both residential and commercial applications - The right choice for all visible areas such as walls and ceilings.


24v Dotless COB strip cool free cutting




Priced per metre

Delivery - Made to measure

Up to 3 business days following payment of invoice.

Delivery  - Off the reel

Order by 1pm for next business day via UPS.



LED strip light specification

UL, TUV CE, CB Approved.
24v Dotless COB strip cool free cutting Colour temperature: Cool white 6000k



Part number

LS24-COB-528-CW-FC


Brightness level

High brightness.

Recommended installation  Dotless LED strip for use on visible areas such as walls & ceilings.
IP rating IP20
Lumen Output
Dimmable  Yes. Compatible with various control systems
Wattage  10 w/m.
Voltage  24V. Constant voltage.
LED quantity  528 LEDS /m.
Width of strip

8mm.

Backing tape  Heavy duty 3M. Secure neatly onto clean surface.
Maximum linear run length capacity

5 metres powered from one end.

10 metres powered from both ends or from the centre.

CRI (Colour rendering Index) High: Rendering colours more realistically.
Lifespan  Up to 50,000 hours.
Cut points on the strip  Free cutting - cut anywhere along the strip. Solder anywhere along the strip.
Warranty  5 years.





Required components

Soldered 2 core cable tail.

Always select the correct cable for your project ensuring efficient current flow & optimal performance.

Quick calculation:

1. Multiply the amount of metres of strip by the wattage:

e.g. 5m strip (@10w/m) 5 x 10 = 50 watts

2. Now divide 50 by 24 (24v)= 2.083A

0.5mm cable capacity  = 3A

0.75mm cable capacity = 6A

In this example - 0.75mm cable is the suitable cable tail option.

Link to 2 core cable >





Shop bespoke options here


SUPPORT:

How to contact us:
Telephone: 02476 262 328
Email: sales@leadingled.co.uk
Connect with us on live chat

Optional compatible components
Smart controller

Wall controller - Set scenes, dim the strip, turn on/off.

Hand held remote Set scenes, dim the strip, turn on/off.

Wifi controller  - For use with smart phone. Set various scenes, dim the brightness, turn on/off.

Smart controller>

Aluminium housing

House LED strip in profile - Diffusion of light, heat dissipation & professional finish.

Aluminium housing>



SPECIFICATION:

 Priced by the metre for a maximum single run length of 5 metres -  (If longer run lengths over 5 metres are required, contact us for advice on how best to install this).

 LED strip is dispatched as one continuous length as per order quantity  - Uncut, unless otherwise stated.

 Cut to measure with soldered cable tails -  Speak with our team to request a bespoke quotation. Alternatively, leave details and measurements for cut to measure LED strip & required length of soldered cable tails in the special instructions box provided at checkout (remember to select the correct cable & solder operation before completing your order).
